Synthetic Leather Production Line — Machine specification
Property
Typical value
Unit
Line type
PU dry transfer-coating, PU wet process, PVC calendering
Working width
1,400 · 1,600 · 1,800
mm
Line speed
5–30
m/min
Coating stations
2–4
stations
Drying oven zones
4–10
zones
Heating
Thermal oil or electric, hot-air circulation
Base substrate
Non-woven, knitted or woven base fabric
Control system
PLC with touchscreen HMI
Web tension
Closed-loop tension control
Machine specifications are configurable. Working width, capacity and line configuration are built to order — the figures shown indicate the typical range available.
Available configurations
PU dry process — release paper transfer coating
PU wet process — DMF coagulation
PVC calendering and laminating
Embossing, printing and surface finishing
Interactive model
A buyer abroad cannot walk the line before ordering, so here it is: rotate, zoom and move through the coating, oven, lamination and cooling stages.
Scope of supply
Supplied as a complete line: mechanical equipment, electrical control cabinets, installation drawings, commissioning supervision and operator training. Scope is agreed in writing before order confirmation.
